Programming your DOOM DRIVER!
Configuration Modes:
Mode 1 - Group Selection
─ Group 1: (task light) → 2% → 20% → 100%
─ Group 2: (task light) → 10% → 40% → 100%
─ Group 3: (task light) → 2% → 10% → 50%
─ Group 4: (task light) → 50% → 100% → Strobe → SOS
Mode 2 - Toggle Memory Mode ON/OF
Mode 3 - Toggle Moonlight Mode ON/OFF
Mode 4 - Reverse Group Order
Mode 5 - Factory Reset
Restarts from Mode 1; this sequence repeats twice if no option is selected.
Programming Guide:
Turn the flashlight ON (full click). From there, half-click/tap the tail-switch 8+ times until it starts to blink (configuration mode).
Hold ON in half-click position once configuration mode is entered and continue with half-clicks/taps and hold to choose modes and groups.
Once Configuration Mode is entered, the light will indicate the available configuration options by blinking:
1 blink → quick flash → 2 blinks → quick flash → 3 blinks → quick flash → 4 blinks → quick flash → 5 blinks → quick flash
The sequence repeats twice if no option is selected.
The number of blinks indicates the configuration option to be changed.
Half-click/tap the tail-switch during the quick flash following the number of blinks to enter the respective configuration mode.
Configuration Modes:
Mode 1 - Group Selection(After entering this menu, the light starts a “blink cycle”, which runs twice. The number of blinks indicates the selected group)
1st blink Group 1 (task light) → 2% → 20% → 100%
2nd blink Group 2 ( task light) → 10% → 40% → 100%
3rd blink Group 3 (task light) → 2% → 10% → 50%
4th blink Group 4 (task light) → 50% → 100% → Strobe → SOS
Half-click/tap the tail-switch after any of the blinks to select the desired group. After the group has been selected, half-click/tap the tail switch to cycle through the brightness steps.
Mode 2 - Toggle Memory Mode (Default OFF)
To switch the memory mode ON, half-click/tap the tail-switch during the quick flash after the second blink.
To switch memory mode OFF, re-enter the configuration mode and repeat the instruction above.
Mode 3 - Toggle Moonlight Mode (Default ON)
To switch the moonlight mode OFF, half-click/tap the tail-switch during the quick flash after the third blink.
To switch the moonlight mode ON again, re-enter the configuration mode and repeat the instruction above.
Mode 4 - Reverse Group Order (default Low-Medium-High)
To reverse the order of the selected group from Low-Medium-High to High-Medium-Low, half-click/tap the tail-switch during the quick flash after the fourth blink.
Repeat to switch back to the original order.
Example: By default, the order of Group 1 is: (Moonlight) → 2% → 20% → 100%
If the order is reversed, Group 1 will be: (Moonlight) → 100% → 20% → 2%
Mode 5 - Factory Reset
Half-click/tap the tail-switch during the quick flash after the fifth blink to reset all options to their original settings.
